The Medlere M3 system provides a fully automated HbA1c and HbA2/F testing solution with ion-exchange technology.
M3 HPLC Hemoglobin Testing System
  • 10.4
    Inch
    Operation screen
  • ＜2
    Mins
    Detection time
  • ≤3%
    CV
    Precision
未命名的设计 (8)
USER-FRIENDLY & TRAINING-READY
The M3 System simplifies HPLC from start to finish, making everything from reagent preparation to result analysis straightforward.
你的段落文字
Specifications
Test principle                                                                                                        Ion-exchange HPLC
Sample type                                                                                                          Venous whole blood/ Capillary fingerstick
Sample volume                                                                                                    5uL
Wavelength                                                                                                           415nm/515nm
Detection time                                                                                                     ＜2 mins
Detection range                                                                                                    4-17%
Repeatability                                                                                                         CV≤3%
Linearity                                                                                                                 R²≥0.99
Pressure range                                                                                                     2.7MPa-6MPa
Dimension                                                                                                             535*310*535mm
Weight                                                                                                                    <32kg
Screen                                                                                                                    10.4-inch touchscreen
Connectivity                                                                                                           LIS/HIS/RS232
Power supply                                                                                                         AC 100-220V，50Hz/60Hz
GOLD STANDARD TECHNOLOGY
EASY TO SWITCH BETWEEN DIFFERENT TEST MODES
EASY TO USE, EASY TO TRAIN
COST-EFFECTIVE
FAQs
  • What is the principle of the Medlere M3 HbA1c testing system?
    加 Created with Sketch.
    形状 Created with Sketch.
    The Medlere M3 employs high-performance liquid chromatography (HPLC) with ion-exchange columns to separate and quantify HbA1c. This method ensures minimal interference from hemoglobin variants and labile A1c.
  • What sample type does the M3 system require?
    加 Created with Sketch.
    形状 Created with Sketch.
    The M3 uses whole blood samples collected in EDTA tubes or fingerstick blood without the need for pre-dilution.
  • How long does it take to analyze one sample?
    加 Created with Sketch.
    形状 Created with Sketch.
    Each sample analysis takes approximately two minutes.
  • What is the purpose of regular HbA1c testing?
    加 Created with Sketch.
    形状 Created with Sketch.
    HbA1c reflects average blood glucose levels over the previous 2-3 months, providing a long-term view of diabetes management. It helps healthcare providers adjust treatment plans.
